Data Contracts in Windows Communication Foundation (WCF)

I’ve been going over data contracts for WCF lately and wanted to post a few specifics. One issue I ran into recently was odd, as it included an enumeration that needed to be included in part of a data contract. I had tagged the enumeration with the [DataContract] attribute but I was receiving an odd issue about the service disconnecting. The error message I was getting was something like this:

I had read, or thought via failed comprehension, that I could just tag an enumeration with [DataContract] as below.

   1:  [DataContract]
   2:  public enum Priority
   3:  {
   4:      Low,
   5:      Medium,
   6:      High
   7:  }

.csharpcode, .csharpcode pre { font-size: small; color: black; font-family: consolas, “Courier New”, courier, monospace; background-color: #ffffff; /*white-space: pre;*/ } .csharpcode pre { margin: 0em; } .csharpcode .rem { color: #008000; } .csharpcode .kwrd { color: #0000ff; } .csharpcode .str { color: #006080; } .csharpcode .op { color: #0000c0; } .csharpcode .preproc { color: #cc6633; } .csharpcode .asp { background-color: #ffff00; } .csharpcode .html { color: #800000; } .csharpcode .attr { color: #ff0000; } .csharpcode .alt { background-color: #f4f4f4; width: 100%; margin: 0em; } .csharpcode .lnum { color: #606060; }

As it turns out though, the [EnumMember] attribute needs added to the enumeration.

   1:  [DataContract]
   2:  public enum Priority
   3:  {
   4:      [EnumMember]
   5:      Low,
   6:      [EnumMember]
   7:      Medium,
   8:      [EnumMember]
   9:      High
  10:  }

.csharpcode, .csharpcode pre { font-size: small; color: black; font-family: consolas, “Courier New”, courier, monospace; background-color: #ffffff; /*white-space: pre;*/ } .csharpcode pre { margin: 0em; } .csharpcode .rem { color: #008000; } .csharpcode .kwrd { color: #0000ff; } .csharpcode .str { color: #006080; } .csharpcode .op { color: #0000c0; } .csharpcode .preproc { color: #cc6633; } .csharpcode .asp { background-color: #ffff00; } .csharpcode .html { color: #800000; } .csharpcode .attr { color: #ff0000; } .csharpcode .alt { background-color: #f4f4f4; width: 100%; margin: 0em; } .csharpcode .lnum { color: #606060; }

After I added that, smooth sailing resumed. So don’t just tag the enumeration, tag the members too. I’m also working on some other notes from my reintroduction to WCF (I’ve done a ton of work with it in the past) so stay tuned for that.

Getting More From Word 2007

I have been using Word 2007 a lot lately writing up technical and how to documents for various projects I’m working on. In addition to that I’ve started looking at word for creating my blog entries. I did get word hooked up to publish blog entries against my BlogEngine.NET entries with the help of a blog post, “Publishing to BlogEngine from Word 2007” on RTUR.NET’s Blog. I also found out where the default theme setting for Word 2007 via the “Setting the default to your liking” entry on The Microsoft Office Word Team’s Blog. The one issue I have that I haven’t found an answer to is how to change the default document that opens when you launch Word 2007.

So if you know how to change that default document I’d be keen to know how.

WCF, Certificate Issues, and Stackoverflow

I’ve been working on getting certificates setup for development with the WCF Web Services I’m building for the High Ball Project.  On a few topics I’m just completely new, like messing with the Certificates, X.509 and SSL and such.  I’m getting there, but road blocks are stopping me every once in a while.  One of my recent issues was how to view the values that the certificate has.  I searched and searched, for some reason I couldn’t find something on MSDN or via Google that would do what I wanted it to do.  In addition to that, the reason I was looking for this application to begin with, I was having issues with getting my web.config settings correct for finding the local certificate I had created with makecert.exe.

Stack Overflow!

That’s when it clicked in my head, hey, I should try this stackoverflow site out!  So I shot over there and posed these two questions and within less than a 24 hr period on the WEEKEND, I got some solid answers.  I gotta say the guys over at stackoverflow are onto something here!

My first question, “Cannot find the X.509 Certificate using the following search criteria:…” and second question “Tool for Viewing X.509 Certificates?” have two great answers.  So check em’ out, and if you aren’t signed up with an OpenID get one and go log into the site!  It rocks.  In addition, for you dot netters out there like me, know that the site is built on ASP.NET MVC!  It’s solid and FAST!

Making Maths Functions n' Stuff Part 6

First off I changed up the UI a little bit to accommodate the changes I wanted to make.  I mainly wanted to show how, at the same time utilizing the functions, the way WPF controls work.  Numerous controls work in ways they never have before, utilizing a more object oriented patterns and practices oriented nomenclature.  I like it, but at the same time it is a learning curve to think of the controls less in their ancient VB4 and VB6 days and more like the real objects that they now are.

   1:  <Window x:Class="Maths.MathsCooking"
   2:      xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
   3:      xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
   4:      Title="Maths Cooking" Height="768" Width="1024">
   5:      <Grid>
   6:          <TextBox Height="65" Margin="10,0,14,50" Name="textAnswers" VerticalAlignment="Bottom" />
   7:          <Button Height="23" HorizontalAlignment="Right" Margin="0,0,14,14" Name="exitApplicationButton" VerticalAlignment="Bottom" Width="75" Click="exitApplicationButton_Click">Exit</Button>
   8:          <GroupBox Header="Fraction Functions" Margin="18,20,489,0" Name="groupBox1" Height="187" VerticalAlignment="Top">
   9:              <Grid HorizontalAlignment="Stretch" VerticalAlignment="Stretch">
  10:                  <Button BorderThickness="3" Click="getApproximateEqualityButton_Click" Height="23" HorizontalAlignment="Right" Margin="0,0,18,23.085" Name="getApproximateEqualityButton" VerticalAlignment="Bottom" Width="150">Get Approximate Equality</Button>
  11:                  <TextBox Height="23" Margin="190,10,198,0" Name="textNumerator" VerticalAlignment="Top"/>
  12:                  <TextBox Height="23" Margin="190,0,198,57.723" Name="textValue" VerticalAlignment="Bottom" />
  13:                  <TextBox Height="23" Margin="190,0,198,21.723" Name="textEpsilon" VerticalAlignment="Bottom"/>
  14:                  <TextBox Height="23" Margin="190,48,198,0" Name="textDenominator" VerticalAlignment="Top"/>
  15:                  <Label Height="28" HorizontalAlignment="Left" Margin="10,10,0,0" Name="labelNumerator" VerticalAlignment="Top" Width="150">Numerator</Label>
  16:                  <Label Height="28" HorizontalAlignment="Left" Margin="10,48,0,0" Name="labelDenominator" VerticalAlignment="Top" Width="150">Denominator</Label>
  17:                  <Label Height="28" HorizontalAlignment="Left" Margin="10,0,0,16.723" Name="labelEpsilon" VerticalAlignment="Bottom" Width="150">Epsilon</Label>
  18:                  <Label Height="28" HorizontalAlignment="Left" Margin="10,0,0,52.723" Name="labelValue" VerticalAlignment="Bottom" Width="150">A Value (Float or Double)</Label>
  19:                  <Button BorderThickness="3" Click="getDecimalButton_Click" Height="23" HorizontalAlignment="Right" Margin="0,46.638,18,0" Name="getDecimalButton" VerticalAlignment="Top" Width="150">Get Decimal</Button>
  20:              </Grid>
  21:          </GroupBox>
  22:          <GroupBox Header="Is Numeric Check" Margin="18,223,489,0" Name="groupBox2" Height="103" VerticalAlignment="Top">
  23:              <Grid HorizontalAlignment="Stretch" VerticalAlignment="Stretch">
  24:                  <Button Height="23" HorizontalAlignment="Right" Margin="0,15,18,0" Name="getAnalysisOfString" VerticalAlignment="Top" Width="150" Click="getAnalysisOfString_Click">Analyze</Button>
  25:                  <TextBox Height="23" Margin="10,15,0,0" Name="textIsNumeric" VerticalAlignment="Top" HorizontalAlignment="Left" Width="95" />
  26:                  <CheckBox Height="16" Margin="142,18,222,0" Name="checkIsNumeric" VerticalAlignment="Top">Is Numeric?</CheckBox>
  27:                  <CheckBox Height="16" Margin="142,0,222,26" Name="checkIsEven" VerticalAlignment="Bottom">Is Even?</CheckBox>
  28:              </Grid>
  29:          </GroupBox>
  30:          <GroupBox Header="GroupBox" Height="187" HorizontalAlignment="Right" Margin="0,20,24,0" Name="groupRounding" VerticalAlignment="Top" Width="446">
  31:              <Grid HorizontalAlignment="Stretch" VerticalAlignment="Stretch">
  32:                  <Button Click="getRoundedAnswers_Click" Height="23" HorizontalAlignment="Right" Margin="0,0,19,23.085" Name="getRoundedAnswers" VerticalAlignment="Bottom" Width="150">Round</Button>
  33:                  <Label Height="28" Margin="160,0,154,54.723" Name="labelRoundDown" VerticalAlignment="Bottom">Down</Label>
  34:                  <Label Height="28" Margin="160,45.999,154,0" Name="lableRoundUp" VerticalAlignment="Top">Up</Label>
  35:                  <Label Height="28" Margin="160,10,154,0" Name="labelRoundIeee" VerticalAlignment="Top">IEEE</Label>
  36:                  <TextBox Height="23" Margin="0,48,19,0" Name="textRoundUp" VerticalAlignment="Top" HorizontalAlignment="Right" Width="120" />
  37:                  <TextBox Height="23" HorizontalAlignment="Right" Margin="0,12,19,0" Name="textRoundIeee" VerticalAlignment="Top" Width="120" />
  38:                  <TextBox Height="23" HorizontalAlignment="Right" Margin="0,0,19,57.723" Name="textRoundDown" VerticalAlignment="Bottom" Width="120" />
  39:                  <TextBox Height="23" HorizontalAlignment="Left" Margin="19,48,0,0" Name="textNumberToRound" VerticalAlignment="Top" Width="120" />
  40:                  <Label HorizontalAlignment="Left" Margin="19,10,0,0" Name="labelNumberToRound" Width="120" Height="28" VerticalAlignment="Top">Round This</Label>
  41:              </Grid>
  42:          </GroupBox>
  43:      </Grid>
  44:  </Window>

.csharpcode, .csharpcode pre { font-size: small; color: black; font-family: consolas, “Courier New”, courier, monospace; background-color: #ffffff; /*white-space: pre;*/ } .csharpcode pre { margin: 0em; } .csharpcode .rem { color: #008000; } .csharpcode .kwrd { color: #0000ff; } .csharpcode .str { color: #006080; } .csharpcode .op { color: #0000c0; } .csharpcode .preproc { color: #cc6633; } .csharpcode .asp { background-color: #ffff00; } .csharpcode .html { color: #800000; } .csharpcode .attr { color: #ff0000; } .csharpcode .alt { background-color: #f4f4f4; width: 100%; margin: 0em; } .csharpcode .lnum { color: #606060; }

After I made the UI changes I altered some of the code and added some code.  The first change was to the but that used to check for numeric value, that now does multiple checks.  The Analyze Button now looks like this.

   1:          private void getAnalysisOfString_Click(object sender, RoutedEventArgs e)
   2:          {
   3:              if (textIsNumeric.Text != string.Empty)
   4:              {
   5:                  bool isNumberic = Functions.IsNumeric(textIsNumeric.Text);
   6:
   7:                  checkIsNumeric.IsChecked = isNumberic;
   8:
   9:                  bool isEven;
  10:                  if (isNumberic)
  11:                  {
  12:                      Int64 numeric = Convert.ToInt64(textIsNumeric.Text);
  13:                      isEven = Functions.IsEven(numeric);
  14:                      checkIsEven.IsChecked = isEven;
  15:                      textAnswers.Text = "Numeric? " + isNumberic + ". Even? " + isEven + ".";
  16:                  }
  17:                  else
  18:                  {
  19:                      textAnswers.Text = "Numeric? " + isNumberic + ".";
  20:                  }
  21:              }
  22:              else
  23:              {
  24:                  MessageBox.Show(
  25:                      "Technically string.empty is not numeric, but it is more useful if you enter a value to check.",
  26:                      "Enter a value!",
  27:                      MessageBoxButton.OK,
  28:                      MessageBoxImage.Hand,
  29:                      MessageBoxResult.OK);
  30:              }
  31:          }

.csharpcode, .csharpcode pre { font-size: small; color: black; font-family: consolas, “Courier New”, courier, monospace; background-color: #ffffff; /*white-space: pre;*/ } .csharpcode pre { margin: 0em; } .csharpcode .rem { color: #008000; } .csharpcode .kwrd { color: #0000ff; } .csharpcode .str { color: #006080; } .csharpcode .op { color: #0000c0; } .csharpcode .preproc { color: #cc6633; } .csharpcode .asp { background-color: #ffff00; } .csharpcode .html { color: #800000; } .csharpcode .attr { color: #ff0000; } .csharpcode .alt { background-color: #f4f4f4; width: 100%; margin: 0em; } .csharpcode .lnum { color: #606060; }

The other functionality I then added was the rounding group box.  The code is included below.

   1:          private void getRoundedAnswers_Click(object sender, RoutedEventArgs e)
   2:          {
   3:              if(Functions.IsNumeric( textNumberToRound.Text))
   4:              {
   5:                  double numberToRound = Convert.ToDouble(textNumberToRound.Text);
   6:                  string roundedUp= Functions.Round(Functions.RoundDirection.Up, numberToRound).ToString();
   7:                  string roundedDown= Functions.Round(Functions.RoundDirection.Down, numberToRound).ToString();
   8:                  string roundedIeee= Functions.Round(Functions.RoundDirection.IeeeStandard, numberToRound).ToString();
   9:                  textRoundUp.Text = roundedUp;
  10:                  textRoundDown.Text = roundedDown;
  11:                  textRoundIeee.Text = roundedIeee;
  12:              }
  13:              else
  14:              {
  15:                  MessageBox.Show(
  16:                      "You must enter numeric values in the text box to round.",
  17:                      "Enter a numeric value!",
  18:                      MessageBoxButton.OK,
  19:                      MessageBoxImage.Hand,
  20:                      MessageBoxResult.OK);
  21:              }
  22:          }

.csharpcode, .csharpcode pre { font-size: small; color: black; font-family: consolas, “Courier New”, courier, monospace; background-color: #ffffff; /*white-space: pre;*/ } .csharpcode pre { margin: 0em; } .csharpcode .rem { color: #008000; } .csharpcode .kwrd { color: #0000ff; } .csharpcode .str { color: #006080; } .csharpcode .op { color: #0000c0; } .csharpcode .preproc { color: #cc6633; } .csharpcode .asp { background-color: #ffff00; } .csharpcode .html { color: #800000; } .csharpcode .attr { color: #ff0000; } .csharpcode .alt { background-color: #f4f4f4; width: 100%; margin: 0em; } .csharpcode .lnum { color: #606060; }

I still have many things I’ll be adding to this strange and haphazard application, as the cooking is never done.  Over the next few months and weeks I intend to add string manipulations and other useful things to the application.  The idea of course, is to use it as reference, and possibly, as something for finding out information!

The code for this entire solution is available at CodePlex: http://www.codeplex.com/csharpcooking
