Go Concurrency Patterns(MapReduce Pattern)

Overview

The MapReduce pattern processes large datasets by breaking the work into two phases: Map (process data in parallel) and Reduce (aggregate results). This pattern is essential for processing large datasets in parallel, distributed computing, data analytics and aggregation, and batch processing jobs.

NOTE: For other posts on concurrency patterns, check out the index post to this series of concurrency patterns.

Implementation Details

Structure

The MapReduce implementation in examples/mapreduce.go consists of three main phases:

1. Map Phase – Splits text into words and emits (word, 1) pairs
2. Shuffle Phase – Groups key-value pairs by key
3. Reduce Phase – Counts occurrences of each word

Code Analysis

Let’s break down the main function and understand how each component works:

func RunMapReduce() {
    // Sample data: words to count
    data := []string{
        "hello world",
        "hello go",
        "world of concurrency",
        "go programming",
        "concurrency patterns",
        "hello concurrency",
        "go world",
        "patterns in go",
    }

    fmt.Printf("Input data: %v\n", data)

    // Map phase: split words and emit (word, 1) pairs
    mapped := mapPhase(data)

    // Shuffle phase: group by key
    grouped := shufflePhase(mapped)

    // Reduce phase: count occurrences
    result := reducePhase(grouped)

    // Display results
    fmt.Println("\nWord count results:")
    for word, count := range result {
        fmt.Printf("  %s: %d\n", word, count)
    }
}

Step-by-step breakdown:

1. Input Data Preparation:
   • data := []string{...} creates a slice of text lines to process
   • Each line contains multiple words that will be counted
   • The data is designed to demonstrate word frequency (e.g., “hello” appears multiple times)
   • This simulates a real-world scenario where you have text documents to analyze
2. Map Phase Execution:
   • mapped := mapPhase(data) processes the input data in parallel
   • Returns a channel of KeyValue pairs where each word is paired with a count of 1
   • This is the first phase of the MapReduce pattern – transforming raw data into key-value pairs
   • The channel-based approach allows for streaming data between phases
3. Shuffle Phase Execution:
   • grouped := shufflePhase(mapped) groups the key-value pairs by key
   • Takes the channel output from the map phase
   • Groups all occurrences of the same word together
   • Returns a map where keys are words and values are slices of counts
4. Reduce Phase Execution:
   • result := reducePhase(grouped) aggregates the grouped data
   • Sums up all the counts for each word
   • Produces the final word count results
   • This is the final phase that produces the desired output
5. Result Display:
   • Iterates through the final results map
   • Displays each word and its total count
   • Shows the complete word frequency analysis

Map Phase Implementation

func mapPhase(data []string) <-chan KeyValue {
    out := make(chan KeyValue, len(data)*10) // Buffer for multiple words per line

    var wg sync.WaitGroup
    for _, line := range data {
        wg.Add(1)
        go func(text string) {
            defer wg.Done()
            words := strings.Fields(strings.ToLower(text))
            for _, word := range words {
                // Simulate some processing time
                time.Sleep(time.Duration(rand.Intn(50)) * time.Millisecond)
                out <- KeyValue{Key: word, Value: 1}
                fmt.Printf("Map: emitted (%s, 1)\n", word)
            }
        }(line)
    }

    go func() {
        wg.Wait()
        close(out)
    }()

    return out
}

Map phase breakdown:

1. Channel Setup:
   • out := make(chan KeyValue, len(data)*10) creates a buffered channel for output
   • Buffer size of len(data)*10 accounts for multiple words per line
   • Buffering prevents blocking when multiple goroutines emit simultaneously
   • Returns a read-only channel (<-chan KeyValue) for encapsulation
2. Parallel Processing Setup:
   • var wg sync.WaitGroup tracks when all map goroutines complete
   • Each line of text gets its own goroutine for parallel processing
   • This enables true parallelism – all lines can be processed simultaneously
3. Goroutine Launch:
   • for _, line := range data iterates through each line of input
   • go func(text string) { ... }(line) launches a goroutine for each line
   • Uses closure to capture the current line in each goroutine
   • wg.Add(1) increments the wait group before each goroutine
4. Word Processing:
   • defer wg.Done() ensures the goroutine signals completion when it exits
   • strings.Fields(strings.ToLower(text)) splits the line into words and converts to lowercase
   • strings.Fields() splits on whitespace, handling multiple spaces correctly
   • strings.ToLower() ensures consistent word matching (case-insensitive)
5. Key-Value Emission:
   • for _, word := range words processes each word in the line
   • time.Sleep(time.Duration(rand.Intn(50)) * time.Millisecond) simulates processing time
   • out <- KeyValue{Key: word, Value: 1} emits a key-value pair for each word
   • Each word gets a value of 1 (will be summed in reduce phase)
6. Channel Cleanup:
   • go func() { wg.Wait(); close(out) }() runs in background
   • Waits for all map goroutines to complete
   • Closes the output channel when all processing is done
   • This signals to downstream phases that no more data is coming

Shuffle Phase Implementation

func shufflePhase(mapped <-chan KeyValue) map[string][]int {
    grouped := make(map[string][]int)
    var mu sync.Mutex

    var wg sync.WaitGroup
    for kv := range mapped {
        wg.Add(1)
        go func(kv KeyValue) {
            defer wg.Done()
            mu.Lock()
            grouped[kv.Key] = append(grouped[kv.Key], kv.Value)
            mu.Unlock()
            fmt.Printf("Shuffle: grouped %s -> %v\n", kv.Key, grouped[kv.Key])
        }(kv)
    }

    wg.Wait()
    return grouped
}

Shuffle phase breakdown:

1. Data Structure Setup:
   • grouped := make(map[string][]int) creates the output map
   • Keys are words (strings), values are slices of counts ([]int)
   • This structure groups all occurrences of each word together
   • var mu sync.Mutex provides thread safety for concurrent map access
2. WaitGroup Setup:
   • var wg sync.WaitGroup tracks when all shuffle goroutines complete
   • Each key-value pair gets its own goroutine for parallel processing
   • This maintains parallelism from the map phase
3. Channel Consumption:
   • for kv := range mapped consumes key-value pairs from the map phase
   • The loop continues until the map phase closes the channel
   • Each key-value pair is processed as it arrives
4. Parallel Grouping:
   • go func(kv KeyValue) { ... }(kv) launches a goroutine for each key-value pair
   • Uses closure to capture the current key-value pair
   • wg.Add(1) increments the wait group before each goroutine
5. Thread-Safe Grouping:
   • defer wg.Done() ensures proper cleanup
   • mu.Lock() and mu.Unlock() protect the shared map during concurrent access
   • grouped[kv.Key] = append(grouped[kv.Key], kv.Value) adds the value to the appropriate group
   • This groups all values for the same key together
6. Completion and Return:
   • wg.Wait() waits for all shuffle goroutines to complete
   • Returns the grouped map with all words and their associated counts
   • The map is now ready for the reduce phase

Reduce Phase Implementation

func reducePhase(grouped map[string][]int) map[string]int {
    result := make(map[string]int)
    var mu sync.Mutex

    var wg sync.WaitGroup
    for word, counts := range grouped {
        wg.Add(1)
        go func(word string, counts []int) {
            defer wg.Done()
            // Simulate some processing time
            time.Sleep(time.Duration(rand.Intn(100)) * time.Millisecond)

            total := 0
            for _, count := range counts {
                total += count
            }

            mu.Lock()
            result[word] = total
            mu.Unlock()
            fmt.Printf("Reduce: %s -> %d\n", word, total)
        }(word, counts)
    }

    wg.Wait()
    return result
}

Reduce phase breakdown:

1. Result Structure Setup:
   • result := make(map[string]int) creates the final output map
   • Keys are words (strings), values are total counts (int)
   • This is the final result structure after aggregation
   • var mu sync.Mutex provides thread safety for concurrent result writing
2. WaitGroup Setup:
   • var wg sync.WaitGroup tracks when all reduce goroutines complete
   • Each word group gets its own goroutine for parallel processing
   • This maintains parallelism for the final aggregation phase
3. Parallel Processing Setup:
   • for word, counts := range grouped iterates through each word and its counts
   • Each word group is processed independently in parallel
   • This allows multiple words to be aggregated simultaneously
4. Goroutine Launch:
   • go func(word string, counts []int) { ... }(word, counts) launches a goroutine for each word
   • Uses closure to capture the current word and its counts
   • wg.Add(1) increments the wait group before each goroutine
5. Aggregation Processing:
   • defer wg.Done() ensures proper cleanup
   • time.Sleep(time.Duration(rand.Intn(100)) * time.Millisecond) simulates processing time
   • total := 0 initializes the sum for this word
   • for _, count := range counts { total += count } sums all counts for the word
6. Thread-Safe Result Storage:
   • mu.Lock() and mu.Unlock() protect the shared result map
   • result[word] = total stores the final count for the word
   • This ensures thread-safe writing to the final result map
7. Completion and Return:
   • wg.Wait() waits for all reduce goroutines to complete
   • Returns the final result map with word counts
   • This completes the MapReduce pattern

Key Design Patterns:

1. Channel-based Data Flow: Channels provide natural streaming between phases with automatic backpressure.
2. Goroutine-per-Item Processing: Each data item gets its own goroutine for true parallelism.
3. Buffered Channels: Appropriate buffering prevents blocking and improves performance.
4. Mutex Protection: Thread-safe access to shared data structures during concurrent operations.
5. WaitGroup Coordination: Proper synchronization ensures all goroutines complete before proceeding.
6. Closure Pattern: func(text string) { ... }(line) captures loop variables in goroutines.
7. Structured Data Types: KeyValue struct provides type safety and clarity.

How It Works

Map Phase

1. Data Input: Receives input data (lines of text)
2. Parallel Processing: Each line is processed in its own goroutine
3. Word Extraction: Splits each line into individual words
4. Key-Value Emission: Emits (word, 1) pairs for each word
5. Channel Output: Sends key-value pairs to the shuffle phase

Shuffle Phase

1. Key-Value Reception: Receives key-value pairs from map phase
2. Parallel Grouping: Each key-value pair is processed in its own goroutine
3. Grouping by Key: Groups values by their keys
4. Thread Safety: Uses mutex to protect the shared grouped map
5. Output Preparation: Prepares grouped data for reduce phase

Reduce Phase

1. Grouped Data Input: Receives grouped data from shuffle phase
2. Parallel Aggregation: Each word group is processed in its own goroutine
3. Value Summation: Sums all values for each key
4. Result Storage: Stores final results in the result map
5. Final Output: Returns the final word count results

Why This Implementation?

Channel-based Communication

• Natural Flow: Channels provide natural data flow between phases
• Backpressure: Automatic backpressure when downstream phases are slow
• Synchronization: Channels handle synchronization between phases
• Composability: Easy to modify or extend individual phases

Goroutine-per-Item Processing

• True Parallelism: Each item is processed independently
• Scalability: Can utilize multiple CPU cores effectively
• Fault Isolation: Failure of one item doesn’t affect others
• Load Distribution: Work is naturally distributed across workers

Buffered Channels

• Performance: Buffered channels reduce blocking between phases
• Memory Management: Appropriate buffer sizes prevent memory issues
• Flow Control: Buffers can handle temporary processing delays
• Efficiency: Reduces context switching overhead

Mutex Protection

• Thread Safety: Protects shared data structures during concurrent access
• Simple Implementation: Straightforward synchronization for grouped data
• Performance: Minimal overhead for the typical MapReduce use case
• Reliability: Ensures data consistency during concurrent operations

Structured Data Types

• Type Safety: KeyValue struct provides type safety
• Clarity: Clear structure makes the code easy to understand
• Extensibility: Easy to extend for different data types
• Debugging: Structured data makes debugging easier

Key Design Decisions

1. Word Count Example: Simple example that clearly demonstrates the pattern
2. Simulated Processing Time: Random delays make concurrency visible
3. Detailed Logging: Output shows the flow through each phase
4. Error Handling: Simple implementation focuses on the core pattern
5. Memory Management: Appropriate buffer sizes prevent memory issues

Performance Characteristics

Throughput

• Parallel Processing: Throughput scales with the number of CPU cores
• Phase Overlap: Phases can overlap in processing (pipelining)
• Memory Usage: Memory usage depends on data size and buffer sizes
• Network Overhead: In distributed systems, network communication adds overhead

Latency

• Processing Time: Latency depends on the slowest phase
• Data Size: Larger datasets increase processing time
• Parallelism: More parallelism reduces latency
• I/O Operations: File I/O can be a significant bottleneck

Scalability

• Horizontal Scaling: Can distribute across multiple machines
• Vertical Scaling: Can utilize multiple CPU cores on single machine
• Data Partitioning: Data can be partitioned for parallel processing
• Load Balancing: Work is naturally distributed across workers

Common Use Cases

Data Processing

• Log Analysis: Process large log files to extract insights
• Text Processing: Analyze text documents for patterns and statistics
• Data Cleaning: Clean and validate large datasets
• ETL Operations: Extract, transform, and load data

Analytics and Reporting

• Business Intelligence: Generate reports from large datasets
• User Behavior Analysis: Analyze user activity patterns
• Performance Metrics: Calculate performance metrics from logs
• Trend Analysis: Identify trends in time-series data

Machine Learning

• Feature Engineering: Extract features from raw data
• Model Training: Process training data for machine learning models
• Data Preprocessing: Prepare data for machine learning algorithms
• Model Evaluation: Evaluate models on large datasets

Search and Indexing

• Web Crawling: Process web pages for search indexing
• Document Indexing: Index large document collections
• Content Analysis: Analyze content for search relevance
• Inverted Index: Build inverted indexes for search engines

Financial Data Processing

• Risk Analysis: Analyze financial data for risk assessment
• Trading Analysis: Process trading data for market analysis
• Fraud Detection: Analyze transactions for fraud patterns
• Portfolio Optimization: Process portfolio data for optimization

Scientific Computing

• Simulation Data: Process simulation results
• Sensor Data: Analyze data from scientific instruments
• Image Processing: Process large image datasets
• Genomic Analysis: Analyze genetic data

Social Media Analysis

• Sentiment Analysis: Analyze social media posts for sentiment
• Trend Detection: Identify trending topics and hashtags
• Network Analysis: Analyze social network connections
• Content Recommendation: Process user behavior for recommendations

Advanced Patterns

Distributed MapReduce

• Multi-node Processing: Distribute processing across multiple machines
• Fault Tolerance: Handle machine failures gracefully
• Load Balancing: Balance load across multiple nodes
• Data Locality: Process data close to where it’s stored

Streaming MapReduce

• Real-time Processing: Process data as it arrives
• Window-based Processing: Process data in time windows
• Incremental Updates: Update results incrementally
• Low Latency: Provide results with minimal delay

Iterative MapReduce

• Multiple Passes: Process data through multiple MapReduce cycles
• Iterative Algorithms: Support for iterative algorithms like PageRank
• Convergence: Continue until convergence criteria are met
• State Management: Maintain state across iterations

The MapReduce pattern is particularly effective when you have:

• Large Datasets: Datasets too large to process on a single machine
• Parallelizable Work: Work that can be divided into independent tasks
• Batch Processing: Operations that can be processed in batches
• Data Analytics: Need to extract insights from large datasets
• Distributed Computing: Need to utilize multiple machines or cores

This pattern provides a powerful framework for processing large datasets efficiently by leveraging parallel processing and distributed computing capabilities.

The final example implementation looks like this:

package examples

import (
	"fmt"
	"math/rand"
	"strings"
	"sync"
	"time"
)

// RunMapReduce demonstrates the MapReduce pattern.
func RunMapReduce() {
	fmt.Println("=== MapReduce Pattern Example ===")

	// Sample data: words to count
	data := []string{
		"hello world",
		"hello go",
		"world of concurrency",
		"go programming",
		"concurrency patterns",
		"hello concurrency",
		"go world",
		"patterns in go",
	}

	fmt.Printf("Input data: %v\n", data)

	// Map phase: split words and emit (word, 1) pairs
	mapped := mapPhase(data)

	// Shuffle phase: group by key
	grouped := shufflePhase(mapped)

	// Reduce phase: count occurrences
	result := reducePhase(grouped)

	// Display results
	fmt.Println("\nWord count results:")
	for word, count := range result {
		fmt.Printf("  %s: %d\n", word, count)
	}

	fmt.Println("\nMapReduce example completed!")
}

// MapPhase splits text into words and emits (word, 1) pairs
func mapPhase(data []string) <-chan KeyValue {
	out := make(chan KeyValue, len(data)*10) // Buffer for multiple words per line

	var wg sync.WaitGroup
	for _, line := range data {
		wg.Add(1)
		go func(text string) {
			defer wg.Done()
			words := strings.Fields(strings.ToLower(text))
			for _, word := range words {
				// Simulate some processing time
				time.Sleep(time.Duration(rand.Intn(50)) * time.Millisecond)
				out <- KeyValue{Key: word, Value: 1}
				fmt.Printf("Map: emitted (%s, 1)\n", word)
			}
		}(line)
	}

	go func() {
		wg.Wait()
		close(out)
	}()

	return out
}

// ShufflePhase groups key-value pairs by key
func shufflePhase(mapped <-chan KeyValue) map[string][]int {
	grouped := make(map[string][]int)
	var mu sync.Mutex

	var wg sync.WaitGroup
	for kv := range mapped {
		wg.Add(1)
		go func(kv KeyValue) {
			defer wg.Done()
			mu.Lock()
			grouped[kv.Key] = append(grouped[kv.Key], kv.Value)
			mu.Unlock()
			fmt.Printf("Shuffle: grouped %s -> %v\n", kv.Key, grouped[kv.Key])
		}(kv)
	}

	wg.Wait()
	return grouped
}

// ReducePhase counts occurrences of each word
func reducePhase(grouped map[string][]int) map[string]int {
	result := make(map[string]int)
	var mu sync.Mutex

	var wg sync.WaitGroup
	for word, counts := range grouped {
		wg.Add(1)
		go func(word string, counts []int) {
			defer wg.Done()
			// Simulate some processing time
			time.Sleep(time.Duration(rand.Intn(100)) * time.Millisecond)

			total := 0
			for _, count := range counts {
				total += count
			}

			mu.Lock()
			result[word] = total
			mu.Unlock()
			fmt.Printf("Reduce: %s -> %d\n", word, total)
		}(word, counts)
	}

	wg.Wait()
	return result
}

// KeyValue represents a key-value pair
type KeyValue struct {
	Key   string
	Value int
}

To run this example, and build the code yourself, check out this and other examples in the go-fluency-concurrency-model-patterns repo. That’s it for this topic, tomorrow I’ll post on the singleflight pattern.
